Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.5 to 6 lpm.
Scale resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 sec. every 24hr after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Filters and solenoid valves.
Chrome-plated brass body and spout.
Anti-blocking safety.
Spout with smooth interior and low volume of water (reduces bacterial niches).
Mixer valves can be fitted, if required.
Delabie DLB-758ENC
BINOPTIC Cross wall electronic basin mixer. L 20mm spout for recessed installation, M 3/-inch fittings
- Controls: Mains supply
- Mount: Panel mounted
- Tap Type: Binoptic
